AQ24N
Compact recessed driveway device (1.5t, 40Kmh), for indoor and outdoor. Anodized aluminum body and front in stainless steel, side emitter plexiglass diffuser. Fixing with screws on its suitable plastic recessed box (supplied with the device), on the floor or on the wall. Suitable as side-marker with lateral light emission at 360°.
Downloads:
| Code | Description | Finitura | Alimentatore Input | Numero Led_ led/m | Colore Luce | Gradi Lente | Lumen Max - Lumen/m | Potenza Max |
|---|---|---|---|---|---|---|---|---|
| 9800500010 | Controcassa per famiglie Inground e Aquarius Ø100mm | Nero | ||||||
| AQ24N8W1H5L | Aquarius 24N 8W LC 360° 24V DC Acciaio inox AISI304 | Acciaio | 24Vdc | 3 |
 Warm light
|
360° | 8W | |
| AQ24N8W2H5L | Aquarius 24N 8W LF 360° 24V DC Acciaio inox AISI304 | Acciaio | 24Vdc | 3 |
 Cold light
|
360° | 8W | |
| AQ24N8W9H5L | Aquarius 24N 8W LN 360° 24V DC Acciaio inox AISI304 | Acciaio | 24Vdc | 3 |
 Natural light
|
360° | 8W |
